7” open frame capacitive touch screen monitor
This 7 inch industrial monitor has a capacitive touch screen integrated in a rugged, durable molded metal product cycle-enclosure. It has a high brightness display, combined with a optical bonded technology, which will increase the clarity of the screen.
The open frame touchscreen monitor delivers the most cost-effective solution for applications such as hospitality, retail, trade shows, gaming, light industrial automation, and much more.
Display Size
7 inch
Display Resolution
1024*600, 16:9
Brightness
1000cd/m2
Contrast Ratio
700:1
View Angle
178/178
Connections
USB
Operating Temperature
-20 to 60c
Mount
VESA-75mm
Features
- Utilizes Optically bonded Touch Panel to LCD Panel
- Capacitive Touch Screen
- Surface treatment: Hard coating (6H)
Display
| Screen Size | 7″ |
| Screen Resolution | 1024 * 600 (WVGA) |
| Screen Ratio | 16:9 |
| Brightness | 1000 nits High Brightness |
Touch Screen
| Touch Screen | Projective Capacitive Touch Screen |
External I/O Ports
| Audio Ports | 1* 3.5mm Audio Line-Out |
| Power Input Port | DC-In (optional Phoenix Type) |
Power
| Input Voltage Range | 12V (optional 9-32V DC) |
| Max Power Consumption | 4.2W |
| Standard Power Adapter | 12V AC/DC Adapter |
Thermal & Environmental
| Cooling Solution | Passive – Fanless |
| Storage Humidity | 10% – 90% Non-condensing |
Enclosure
| Material | Aluminum |
| IP Rating | IP65 Front Bezel |
| Color | Silver |
| Mounting Options | Panel Mount, VESA Mount |
