17″ Panel PC
17″ 1024*768 LED Backlight Full Flat capactive Touch Screen
Multiple CPU options (Intel 1037U/J1900 i3/i5)
IP65 Rated Front Bezel
Rich I/Os : COM, USB, LAN, HDMI/VGA…
Reliable fully enclosed design through a aluminum housing, which effectively prevents dust and dirt.
Model Number: EB-LF17
RESUN’s 17″ Fanless Industrial Touch Screen Panel PC
The Industrial Panel PC # EB-LF17 is specifically designed with a fully seamless metal body which effectively prevents dust and dirt into the computer case.
The IP65 compliant front bezel provides protection from water and moisture damage and can even withstand high-pressure water jets enabling the fully flat touch screen surface to be easily cleaned. This feature makes this 17″ Touch Screen PC especially suitable for applications where stringent hygiene levels are important, such as within the food and beverages industry.
| General Information | Material | Aluminum | ||||||||
| Color | Black | |||||||||
| IP grade | Front panel IP65 | |||||||||
| VESA mounting | 75×75mm/100×100mm | |||||||||
| Installation Method | Default Embedded (clip holes on sides, wall-mounting…) | |||||||||
| PC | CPU | Intel® Celeron 1037U, Dual-core , 1.8GHz, fanless | ||||||||
| Chipset | Haswell | |||||||||
| Memory | 2G DDR3 (4G,8G optional) | |||||||||
| Hard Drive Capacity | 64G SSD | |||||||||
| Hard Drive Optional | SSD: 32G,128GB,256G,512GB | |||||||||
| HDD: 500GB,1TB | ||||||||||
| Wireless Network | WIFI/ 802.11a/b/g/n | |||||||||
| I/O Interface | 3×USB 2.0,1×USB 3.0, 2 x COM RS232 | |||||||||
| 1×VGA/HD*MI/RJ45/Audio OUT/POWER DC | ||||||||||
| Operation System | Support Win 10 PRO | |||||||||
| LCD panel | Support Colortime | 16.7M colors | ||||||||
| Brightness (cd/m²) | 300 | |||||||||
| Point Distance | 0.264mm | |||||||||
| Response time | 5ms | |||||||||
| Contrast ratio | 1000:1 | |||||||||
| View angle | 75°/75°/75°/75° (R/L/U/D) | |||||||||
| Viewing angle | 160 deg / 160 deg | |||||||||
| Touch panel | Touch screen Type | Capacitive touch screen | ||||||||
| Touch Interface | USB | |||||||||
| Touch response time | <5ms | |||||||||
| Luminousness | 90% | |||||||||
| Working Life | >50 million times | |||||||||
| Power Supply | External Power Supply | AC 100 – 240V | ||||||||
| Working voltage | DC 12V | |||||||||
| Power consumption | ≤45W | |||||||||
| Other Information | Ambient humidity | 5~85%, non-condensable | ||||||||
| Working temperature | -20°C~70°C | |||||||||
