12.1″ Touch Screen RFID Access Control Terminal
12.1 inch TFT LCD touch screen, all operations can be done directly on the touch screen
Integrated with Intel J1900 Quad cors CPU
Dual 125KHz-EM or 13.56MHz-Mifare RFID reading capacity
Windows or Linux operating system support
IP65 Front panel watertight and dustproof
Model NO.: EB-121RA-OEM
RFID Access Control and Time Attendance with touch screen, Panel PC, Support Windows, Linux, Fingerprint is optional.
This 12.1 inch RFID touch screen computer, an intelligent all-in-one access control terminal that reads both MIFARE and EM tags and also optional for NFC.
The fanless panel PCs are built on the low power, low heat chipsets.
This is RFID Touch Computer systems combine IP65 compliant front panel with CNC cutted shields
to ensure the computer is secured against vandalism and protected against extreme environmental conditions.
| CPU | Intel® Celeron® Processor J1900 (2M Cache, up to 2.42 GHz) | ||||
| Chipsets | Intel® Bay Trail SOC | ||||
| RAM | 2GByte DDR3L-1600 | ||||
| Hard Drive | 32GB SSD | ||||
| Graphic | Intel HD Graphics | ||||
| Audio | Realtek HD ALC 662 ,2*2W Loudspeaker | ||||
| LAN | Realtek RTL8111F , 1*10/100/1000MBit RJ45 Ports | ||||
| External Ports | HDMI | ||||
| 2*USB2.0 , 2*USB3.0 | |||||
| 2* COM | |||||
| 1*RJ45 | |||||
| VGA | |||||
| Line out | |||||
| MIC | |||||
| Power on/off | |||||
| DC-in(12V) input power | |||||
| Internal port | 1*Sata 300MB/S (1*MSATA) | ||||
| 1*MiniPCI-E | |||||
| RFID | 125Khz / ID card (EM4100) | ||||
| 13.56Mhz / IC card (ISO14443A) | |||||
| Driver | Windows, Linux; | ||||
| Aspect Ratio | 16:10 | ||||
| Physical Resolution | 1280（W)*800(H) | ||||
| Brightness | 400 | ||||
| Touch Panel | 4 wire Resistive touch panel | ||||
| Front Panel | IP65 | ||||
| Case | Aluminum ,steel sheet | ||||
